Commercial
Insulated
Pin Terminals

Filter
1175-403-04411
1175-403-04411
1175-403-04411
0.506" - - PRESS LOCK 3/32 0.142 (+0.003/-0.001) Brass Bright Tin - - PTFE Brown NO
1175-601-0416
1175-601-0416
1175-601-0416
0.424" - - PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Electro-Tin - - PTFE Blue YES
1175-601-0411
1175-601-0411
1175-601-0411
0.424" - - PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Electro-Tin - - PTFE Brown NO
1175-461-04415
1175-461-04415
1175-461-04415
0.361" - - PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Bright Tin - - PTFE Green YES
1110-41-0318
1110-41-0318
1110-41-0318
0.937" 0.049 Pin/Pin Press Fit 1/16 0.156 Brass Gold - - PTFE Gray NO
1156-15-0117
1156-15-0117
1156-15-0117
1.061" 0.050 DOUBLE TURRET/PIN Press Fit 7/32 0.158 Brass Silver - - PTFE Violet YES
1156-14-0318
1156-14-0318
1156-14-0318
0.836" 0.050 DOUBLE Turret/Tip Press Fit Up to 3/16 0.158 Brass Gold - - PTFE Gray NO
1124-03-0516
1124-03-0516
1124-03-0516
1.274" 0.050 THREAD/TIP Press Fit Up to 3/8 0.158 Brass Electro Solder - - PTFE Blue NO
1121-23-0412
1121-23-0412
1121-23-0412
1.965" 0.050 Turret/Tip Press Fit 49/64 0.158 Brass Electro-Tin - - PTFE Red NO
1125-03-08812
1125-03-08812
1125-03-08812
0.485" - - 4-40 1/8 4-40 THREAD Brass Bright Tin-Lead Electro-Tin Brass PTFE Red NO
1102R-58-0312
1102R-58-0312
1102R-58-0312
0.405" - - Press Fit 1/8 0.158 Brass Gold - - PTFE Red NO
1135-02-0410
1135-02-0410
1135-02-0410
0.471" 0.030 Pin/Slotted Press Fit 1/32 0.070 Brass Electro-Tin - - PTFE Black YES
09-2089-1-0310
09-2089-1-0310
09-2089-1-0310
0.360" 0.030 TURRET/PIN Press Fit 1/16 0.070 Brass Gold - - PTFE Black YES
1119-26-0117
1119-26-0117
1119-26-0117
1.500" 0.032 TURRET/PIN Press Fit 1/16 0.070 Brass Silver - - PTFE Violet YES
1139-03-0410
1139-03-0410
1139-03-0410
0.448" 0.030 Pin/Pin Press Fit 1/16 0.070 Brass Electro-Tin - - PTFE Black YES
1135-02-0113
1135-02-0113
1135-02-0113
0.471" 0.030 Pin/Slotted Press Fit 1/32 0.070 Brass Silver - - PTFE Orange NO
1137-03-04411
1137-03-04411
1137-03-04411
0.320" 0.030 Pin/Slotted Press Fit 1/16 0.070 Brass Bright Tin - - PTFE Brown NO
1119-25-04410
1119-25-04410
1119-25-04410
1.500" 0.030 TURRET/PIN Press Fit 3/32 0.070 Brass Bright Tin - - PTFE Black YES
1119-22-04411
1119-22-04411
1119-22-04411
1.500" 0.030 TURRET/PIN Press Fit 3/32 0.070 Brass Bright Tin - - PTFE Brown NO
1126-25-08811
1126-25-08811
1126-25-08811
0.594" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Bright Tin-Lead ZINC Brass PTFE Brown NO
