Commercial
Insulated
Pin Terminals

Filter
1100-44-0119
1100-44-0119
1100-44-0119
0.547" 0.040 - Press Fit 1/8 0.152 Brass Silver - - PTFE White YES
1102-51-0512
1102-51-0512
1102-51-0512
0.831" - - Press Fit 1/8 0.152 Brass Electro Solder - - PTFE Red NO
1102-33-0114
1102-33-0114
1102-33-0114
0.493" - - Press Fit 1/8 0.152 Brass Silver - - PTFE Yellow NO
1102-32-08819
1102-32-08819
1102-32-08819
0.468" - - Press Fit 3/32 0.152 Brass Bright Tin-Lead - - PTFE White NO
1100-45-0317
1100-45-0317
1100-45-0317
0.718" 0.040 - Press Fit Up to 3/16 0.152 Brass Gold - - PTFE Violet YES
1100-45-0318
1100-45-0318
1100-45-0318
0.718" 0.040 - Press Fit Up to 3/16 0.152 Brass Gold - - PTFE Gray NO
1100-45-0517
1100-45-0517
1100-45-0517
0.718" 0.040 - Press Fit Up to 3/16 0.152 Brass Electro Solder - - PTFE Violet NO
1110-40-0517
1110-40-0517
1110-40-0517
0.675" 0.040 Pin/Pin Press Fit 1/8 0.152 Brass Electro Solder - - PTFE Violet NO
1110-40-0518
1110-40-0518
1110-40-0518
0.675" 0.040 Pin/Pin Press Fit 1/8 0.152 Brass Electro Solder - - PTFE Gray NO
1102-44-0514
1102-44-0514
1102-44-0514
0.750" - - Press Fit 1/16 0.152 Brass Electro Solder - - PTFE Yellow NO
1102-44-0511
1102-44-0511
1102-44-0511
0.750" - - Press Fit 1/16 0.152 Brass Electro Solder - - PTFE Brown NO
1102-44-04413
1102-44-04413
1102-44-04413
0.750" - - Press Fit 1/16 0.152 Brass Bright Tin - - PTFE Orange NO
1102-04-0410
1102-04-0410
1102-04-0410
0.346" - - Press Fit 1/32 0.091 Brass Electro-Tin - - PTFE Black YES
1106-02-0417
1106-02-0417
1106-02-0417
0.478" - - Press Fit 1/8 0.158 Brass Electro-Tin - - PTFE Violet YES
1100-61-0317
1100-61-0317
1100-61-0317
1.025" 0.040 - Press Fit 1/16 0.086 Brass Gold - - PTFE Violet YES
1100-61-0513
1100-61-0513
1100-61-0513
1.025" 0.040 - Press Fit 1/16 0.086 Brass Electro Solder - - PTFE Orange NO
1100-61-0514
1100-61-0514
1100-61-0514
1.025" 0.040 - Press Fit 1/16 0.086 Brass Electro Solder - - PTFE Yellow NO
1106-02-0415
1106-02-0415
1106-02-0415
0.478" - - Press Fit 1/8 0.158 Brass Electro-Tin - - PTFE Green YES
1106-02-0416
1106-02-0416
1106-02-0416
0.478" - - Press Fit 1/8 0.158 Brass Electro-Tin - - PTFE Blue YES
1151R-10-0119
1151R-10-0119
1151R-10-0119
0.415" - - Press Fit 3/32 0.136 Brass Silver - - PTFE White YES
