Commercial
Insulated
Pin Terminals

Filter
1152R-02-0313
1152R-02-0313
1152R-02-0313
0.375" 0.040 - Press Fit 3/32 0.136 Brass Gold - - PTFE Orange NO
1123-02-0315
1123-02-0315
1123-02-0315
0.821" 0.050 TIP/SLOTTED Press Fit Up to 3/16 0.158 Brass Gold - - PTFE Green YES
1127-02-0113
1127-02-0113
1127-02-0113
0.423" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Silver ZINC Brass DIALLYL PHTHALATE Orange YES
1108-02-08814
1108-02-08814
1108-02-08814
2.287" - Double Turret/Double Turret Press Fit 7/8 0.205 Brass Bright Tin-Lead - - PTFE Yellow NO
1127-02-0110
1127-02-0110
1127-02-0110
0.423" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Silver ZINC Brass DIALLYL PHTHALATE Black YES
1108-02-08812
1108-02-08812
1108-02-08812
2.287" - Double Turret/Double Turret Press Fit 7/8 0.205 Brass Bright Tin-Lead - - PTFE Red NO
1127-02-0117
1127-02-0117
1127-02-0117
0.423" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Silver ZINC Brass DIALLYL PHTHALATE Violet YES
1153-02-0312
1153-02-0312
1153-02-0312
0.515" 0.040 Pin/Pin Press Fit 1/16 0.113 Brass Gold - - PTFE Red NO
1151-02-0518
1151-02-0518
1151-02-0518
0.350" - - Press Fit 1/16 0.086 Brass Electro Solder - - PTFE Gray NO
1151-02-0517
1151-02-0517
1151-02-0517
0.350" - - Press Fit 1/16 0.086 Brass Electro Solder - - PTFE Violet NO
1113-02-0318
1113-02-0318
1113-02-0318
0.303" - - Press Fit 1/32 0.113 Brass Gold - - PTFE Gray NO
1113-02-0312
1113-02-0312
1113-02-0312
0.303" - - Press Fit 1/32 0.113 Brass Gold - - PTFE Red NO
1115R-02-0315
1115R-02-0315
1115R-02-0315
0.282" 0.040 - Press Fit 1/32 0.136 Brass Gold - - PTFE Green YES
1154-02-08810
1154-02-08810
1154-02-08810
0.540" - - Press Fit 1/8 0.158 Brass Bright Tin-Lead - - PTFE Black NO
1154-02-08812
1154-02-08812
1154-02-08812
0.540" - - Press Fit 1/8 0.158 Brass Bright Tin-Lead - - PTFE Red NO
1106-02-0511
1106-02-0511
1106-02-0511
0.478" - - Press Fit 1/8 0.158 Brass Electro Solder - - PTFE Brown NO
1106-02-0513
1106-02-0513
1106-02-0513
0.478" - - Press Fit 1/8 0.158 Brass Electro Solder - - PTFE Orange NO
1106-02-0514
1106-02-0514
1106-02-0514
0.478" - - Press Fit 1/8 0.158 Brass Electro Solder - - PTFE Yellow NO
1106-02-0516
1106-02-0516
1106-02-0516
0.478" - - Press Fit 1/8 0.158 Brass Electro Solder - - PTFE Blue NO
1131-02-0514
1131-02-0514
1131-02-0514
0.648" (0.040)/(0.090) Pin/Tip Press Fit Up to 1/4 0.172 Brass Electro Solder - - PTFE Yellow NO
