Commercial
Insulated
Pin Terminals

Filter
1151R-06-0117
1151R-06-0117
1151R-06-0117
0.375" - - Press Fit 3/32 0.136 Brass Silver - - PTFE Violet YES
1151R-06-0118
1151R-06-0118
1151R-06-0118
0.375" - - Press Fit 3/32 0.136 Brass Silver - - PTFE Gray NO
1130-06-0411
1130-06-0411
1130-06-0411
1.937" (0.030)/(0.050) Pin/Pin Press Fit 3/32 0.172 Brass Electro-Tin - - PTFE Brown NO
1127-06-0410
1127-06-0410
1127-06-0410
0.390" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Electro-Tin ZINC Brass DIALLYL PHTHALATE Black YES
1157-06-08818
1157-06-08818
1157-06-08818
1.115" 0.050 TURRET/PIN Press Fit 11/32 0.158 Brass Bright Tin-Lead - - PTFE Gray NO
1156R-06-0412
1156R-06-0412
1156R-06-0412
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Red NO
1108-06-0312
1108-06-0312
1108-06-0312
0.819" - Double Turret/Double Turret Press Fit Up to 3/16 0.174 Brass Gold - - PTFE Red NO
1125-06-04412
1125-06-04412
1125-06-04412
0.414" - - Swage Mount 1/32 0.116 ±0.002 Brass Bright Tin Electro-Tin Brass PTFE Red NO
1157-06-08817
1157-06-08817
1157-06-08817
1.115" 0.050 TURRET/PIN Press Fit 11/32 0.158 Brass Bright Tin-Lead - - PTFE Violet NO
1125-06-0419
1125-06-0419
1125-06-0419
0.414" - - Swage Mount 1/32 0.116 ±0.002 Brass Electro-Tin Electro-Tin Brass PTFE White YES
1156R-06-0413
1156R-06-0413
1156R-06-0413
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Orange NO
1156R-06-0418
1156R-06-0418
1156R-06-0418
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Gray NO
1130R-06-08814
1130R-06-08814
1130R-06-08814
1.937" (0.030)/(0.050) Pin/Pin Press Fit 3/32 0.172 Brass Bright Tin-Lead - - PTFE Yellow NO
1103-06-0319
1103-06-0319
1103-06-0319
0.520" - - Press Fit 1/8 0.152 Brass Gold - - PTFE White YES
1130-06-04412
1130-06-04412
1130-06-04412
1.937" (0.030)/(0.050) Pin/Pin Press Fit 3/32 0.172 Brass Bright Tin - - PTFE Red NO
1153-06-0411
1153-06-0411
1153-06-0411
0.515" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Brown NO
1121-06-04412
1121-06-04412
1121-06-04412
0.493" 0.040 Turret/Tip Press Fit 1/8 0.136 Brass Bright Tin - - PTFE Red NO
1125-06-08815
1125-06-08815
1125-06-08815
0.414" - - Swage Mount 1/32 0.116 ±0.002 Brass Bright Tin-Lead Electro-Tin Brass PTFE Green NO
1121-06-04413
1121-06-04413
1121-06-04413
0.493" 0.040 Turret/Tip Press Fit 1/8 0.136 Brass Bright Tin - - PTFE Orange NO
1121-06-04417
1121-06-04417
1121-06-04417
0.493" 0.040 Turret/Tip Press Fit 1/8 0.136 Brass Bright Tin - - PTFE Violet YES
