Commercial
Insulated
Pin Terminals

Filter
1123R-07-0416
1123R-07-0416
1123R-07-0416
1.197" 0.050 TIP/SLOTTED Press Fit 11/32 0.158 Brass Electro-Tin - - PTFE Blue YES
1123R-07-0415
1123R-07-0415
1123R-07-0415
1.197" 0.050 TIP/SLOTTED Press Fit 11/32 0.158 Brass Electro-Tin - - PTFE Green YES
1123R-07-0412
1123R-07-0412
1123R-07-0412
1.197" 0.050 TIP/SLOTTED Press Fit 11/32 0.158 Brass Electro-Tin - - PTFE Red NO
1112-07-0417
1112-07-0417
1112-07-0417
0.273" - - Press Fit 1/16 0.113 Brass Electro-Tin - - PTFE Violet YES
1110-07-0515
1110-07-0515
1110-07-0515
0.355" 0.040 Pin/Pin Press Fit 1/32 0.113 Brass Electro Solder - - PTFE Green NO
1157-07-0514
1157-07-0514
1157-07-0514
0.350" 0.040 Turret/Tip Press Fit 1/16 0.158 Brass Electro Solder - - PTFE Yellow NO
1157-07-0513
1157-07-0513
1157-07-0513
0.350" 0.040 Turret/Tip Press Fit 1/16 0.158 Brass Electro Solder - - PTFE Orange NO
1157-07-0512
1157-07-0512
1157-07-0512
0.350" 0.040 Turret/Tip Press Fit 1/16 0.158 Brass Electro Solder - - PTFE Red NO
1103-07-08819
1103-07-08819
1103-07-08819
0.519" - - Press Fit Up to 3/16 0.158 Brass Bright Tin-Lead - - PTFE White NO
1103-07-08810
1103-07-08810
1103-07-08810
0.519" - - Press Fit Up to 3/16 0.158 Brass Bright Tin-Lead - - PTFE Black NO
1112-07-08811
1112-07-08811
1112-07-08811
0.273" - - Press Fit 1/16 0.113 Brass Bright Tin-Lead - - PTFE Brown NO
1121R-07-08811
1121R-07-08811
1121R-07-08811
0.500" 0.040 Turret/Tip Press Fit 3/32 0.136 Brass Bright Tin-Lead - - PTFE Brown NO
1135-07-08815
1135-07-08815
1135-07-08815
0.400" 0.030 Pin/Slotted Press Fit 1/16 0.086 Brass Bright Tin-Lead - - PTFE Green NO
1175-763-0319
1175-763-0319
1175-763-0319
0.419" - - PRESS LOCK 3/32 0.154 (+0.003/-0.001) Brass Gold - - PTFE White YES
1157-04-08810
1157-04-08810
1157-04-08810
0.740" 0.050 TURRET/PIN Press Fit Up to 3/16 0.158 Brass Bright Tin-Lead - - PTFE Black NO
1157-04-0410
1157-04-0410
1157-04-0410
0.740" 0.050 TURRET/PIN Press Fit Up to 3/16 0.158 Brass Electro-Tin - - PTFE Black YES
1157-04-0413
1157-04-0413
1157-04-0413
0.740" 0.050 TURRET/PIN Press Fit Up to 3/16 0.158 Brass Electro-Tin - - PTFE Orange NO
1114-23-04412
1114-23-04412
1114-23-04412
0.367" 0.085 - Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Red NO
1157-04-08811
1157-04-08811
1157-04-08811
0.740" 0.050 TURRET/PIN Press Fit Up to 3/16 0.158 Brass Bright Tin-Lead - - PTFE Brown NO
1111R-04-08818
1111R-04-08818
1111R-04-08818
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/32 0.113 Brass Bright Tin-Lead - - PTFE Gray NO
