Commercial
Insulated
Pin Terminals

Filter
1114R-68-0413
1114R-68-0413
1114R-68-0413
0.150" - - Press Fit 1/32 0.113 Brass Electro-Tin - - PTFE Orange NO
1114R-68-0511
1114R-68-0511
1114R-68-0511
0.150" - - Press Fit 1/32 0.113 Brass Electro Solder - - PTFE Brown NO
1102-06-08811
1102-06-08811
1102-06-08811
0.531" - - Press Fit 1/16 0.114 Brass Bright Tin-Lead - - PTFE Brown NO
1110-11-0518
1110-11-0518
1110-11-0518
0.515" 0.040 Pin/Pin Press Fit 1/32 0.113 Brass Electro Solder - - PTFE Gray NO
1106R-51-0316
1106R-51-0316
1106R-51-0316
0.150" - - Press Fit 1/32 0.113 Brass Gold - - PTFE Blue YES
1110-16-0519
1110-16-0519
1110-16-0519
0.375" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Electro Solder - - PTFE White NO
1100R-51-04415
1100R-51-04415
1100R-51-04415
0.310" 0.040 - Press Fit 1/32 0.113 Brass Bright Tin - - PTFE Green YES
1112R-05-0510
1112R-05-0510
1112R-05-0510
0.200" - - Press Fit 1/32 0.113 Brass Electro Solder - - PTFE Black NO
1102-03-0512
1102-03-0512
1102-03-0512
0.350" - - Press Fit 1/16 0.086 Brass Electro Solder - - PTFE Red NO
1112R-05-0412
1112R-05-0412
1112R-05-0412
0.200" - - Press Fit 1/32 0.113 Brass Electro-Tin - - PTFE Red NO
1110-07-0312
1110-07-0312
1110-07-0312
0.355" 0.040 Pin/Pin Press Fit 1/32 0.113 Brass Gold - - PTFE Red NO
1112-06-0313
1112-06-0313
1112-06-0313
0.233" - - Press Fit 1/32 0.113 Brass Gold - - PTFE Orange NO
1126-36-0418
1126-36-0418
1126-36-0418
0.890" - - 4-40 Nut 1/8 0.120 Brass Electro-Tin ZINC Brass PTFE Gray NO
1113-58-04416
1113-58-04416
1113-58-04416
0.559" 0.080 PIN/Solder CUP Press Fit 1/8 0.172 Brass Bright Tin - - PTFE Blue YES
1110-48-0112
1110-48-0112
1110-48-0112
0.540" 0.046 Pin/Pin Press Fit 1/8 0.158 Brass Silver - - PTFE Red NO
1104R-53-08817
1104R-53-08817
1104R-53-08817
0.555" - - Press Fit 1/8 0.158 Brass Bright Tin-Lead - - PTFE Violet NO
1104R-53-08812
1104R-53-08812
1104R-53-08812
0.555" - - Press Fit 1/8 0.158 Brass Bright Tin-Lead - - PTFE Red NO
1114-18-08817
1114-18-08817
1114-18-08817
0.250" 0.040 - Press Fit 1/32 0.136 Brass Bright Tin-Lead - - PTFE Violet NO
1102-71-08818
1102-71-08818
1102-71-08818
1.268" - - Press Fit 5/32 0.158 Brass Bright Tin-Lead - - PTFE Gray NO
1102-17-0317
1102-17-0317
1102-17-0317
0.461" - - Press Fit 1/8 0.136 Brass Gold - - PTFE Violet YES
