Non-Insulated
PC Jacks

Filter
09-9008-1-088
09-9008-1-088
09-9008-1-088
0.040 0.192 " 0.317" - Solder - 1/32 - 3/32 0.089 Brass Bright Tin-Lead Vertical
09-9166-1-035
09-9166-1-035
09-9166-1-035
0.060 0.200 " 0.540" Jack/Edge Mount Screw Mount - - 0.063 (+0.003/-0.000) Brass Gold Horizontal
09-9026-2-035
09-9026-2-035
09-9026-2-035
0.016 - 0.019 0.207 " 0.235" - Solder - 1/32 - 5/32 0.052 Brass Gold Vertical
09-9275-1-03
09-9275-1-03
09-9275-1-03
0.080 0.350 " 0.466" - - - - - Brass Gold -
09-9281-1-035
09-9281-1-035
09-9281-1-035
0.030 - 0.032 0.190 " 0.388" Jack/Turret Solder - 1/32 - 5/32 0.076 (+0.002/-0.001) Brass Gold Vertical
09-9662-2-03
09-9662-2-03
09-9662-2-03
0.015 - 0.021 0.092 " 0.138" - Solder - 1/32 - 3/32 0.041 Brass Gold Vertical
09-9094-1-04
09-9094-1-04
09-9094-1-04
0.080 0.325 " 0.537" Jack/Pin Solder - 1/32 - 3/32 0.062 Brass Electro-Tin Horizontal
09-9016-2-035
09-9016-2-035
09-9016-2-035
0.025 0.144 " 0.387" Jack/Pin Swage Mount 0.082" 1/16 0.062 Brass Gold Vertical
09-9620-3-04
09-9620-3-04
09-9620-3-04
0.032 - 0.046 0.200 " 0.355" - Swage Mount 0.125" 3/32 0.067 Brass Electro-Tin Vertical
09-9620-2-035
09-9620-2-035
09-9620-2-035
0.032 - 0.046 0.200 " 0.324" - Swage Mount 0.094" 1/16 0.067 Brass Gold Vertical
09-9620-2-063
09-9620-2-063
09-9620-2-063
0.032 - 0.046 0.200 " 0.324" - Swage Mount 0.094" 1/16 0.067 Brass Bright Tin-Lead Vertical
09-9620-2-088
09-9620-2-088
09-9620-2-088
0.032 - 0.046 0.200 " 0.324" - Swage Mount 0.094" 1/16 0.067 Brass Bright Tin-Lead Vertical
09-9620-4-03
09-9620-4-03
09-9620-4-03
0.032 - 0.046 0.200 " 0.386" - Swage Mount 0.156" 1/8 0.067 Brass Gold Vertical
09-9620-3-03
09-9620-3-03
09-9620-3-03
0.032 - 0.046 0.200 " 0.355" - Swage Mount 0.125" 3/32 0.067 Brass Gold Vertical
09-9620-4-04
09-9620-4-04
09-9620-4-04
0.032 - 0.046 0.200 " 0.386" - Swage Mount 0.156" 1/8 0.067 Brass Electro-Tin Vertical
09-9045-3-035
09-9045-3-035
09-9045-3-035
0.025 0.141 " 0.303" Jack/Turret Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9045-3-04
09-9045-3-04
09-9045-3-04
0.025 0.141 " 0.303" Jack/Turret Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9045-4-035
09-9045-4-035
09-9045-4-035
0.025 0.141 " 0.334" Jack/Turret Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9045-4-04
09-9045-4-04
09-9045-4-04
0.025 0.141 " 0.334" Jack/Turret Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9045-4-063
09-9045-4-063
09-9045-4-063
0.025 0.141 " 0.334" Jack/Turret Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
