Military
Insulated
Terminals

Filter
1114R-23M-09513
1114R-23M-09513
1114R-23M-09513
0.367" - Press Fit 1/16 0.136 PTFE Orange M55155/063I02 AA59126/063I02
1114R-23M-0512
1114R-23M-0512
1114R-23M-0512
0.367" - Press Fit 1/16 0.136 PTFE Red M55155/062H02 AA59126/062H02
1114R-23M-0515
1114R-23M-0515
1114R-23M-0515
0.367" - Press Fit 1/16 0.136 PTFE Green M55155/065H02 AA59126/065H02
1114R-23M-0514
1114R-23M-0514
1114R-23M-0514
0.367" - Press Fit 1/16 0.136 PTFE Yellow M55155/064H02 AA59126/064H02
1100-28M-09519
1100-28M-09519
1100-28M-09519
0.350" - Press Fit 1/16 0.136 PTFE White M55155/089I01 AA59126/089I01
1100-28M-0517
1100-28M-0517
1100-28M-0517
0.350" - Press Fit 1/16 0.136 PTFE Violet M55155/087H01 AA59126/087H01
1110-21M-08811
1110-21M-08811
1110-21M-08811
0.515" Pin/Pin Press Fit 1/16 0.136 PTFE Brown M55155/031J02 AA59126/031J02
1169-37M-08819
1169-37M-08819
1169-37M-08819
0.750" - 4-40 Nut 1/8 0.120 DIALLYL PHTHALATE White M55155/099J04 AA59126/099J04
1125-43M-0517
1125-43M-0517
1125-43M-0517
0.750" - 4-40 Nut 1/8 0.120 PTFE Violet M55155/097H01 AA59126/097H01
1127-68M-0518
1127-68M-0518
1127-68M-0518
0.593" - 2-56 Nut 3/32 0.094 DIALLYL PHTHALATE Gray M55155/188H01 AA59126/188H01
1127-68M-09516
1127-68M-09516
1127-68M-09516
0.593" - 2-56 Nut 3/32 0.094 DIALLYL PHTHALATE Blue M55155/186I01 AA59126/186I01
1127-69M-08813
1127-69M-08813
1127-69M-08813
0.750" - 2-56 Nut 3/32 0.094 DIALLYL PHTHALATE Orange M55155/183J02 AA59126/183J02
1127-68M-08816
1127-68M-08816
1127-68M-08816
0.593" - 2-56 Nut 3/32 0.094 DIALLYL PHTHALATE Blue M55155/186J01 AA59126/186J01
1127-69M-08812
1127-69M-08812
1127-69M-08812
0.750" - 2-56 Nut 3/32 0.094 DIALLYL PHTHALATE Red M55155/182J02 AA59126/182J02
1127-69M-0512
1127-69M-0512
1127-69M-0512
0.750" - 2-56 Nut 3/32 0.094 DIALLYL PHTHALATE Red M55155/182H02 AA59126/182H02
1127-69M-0513
1127-69M-0513
1127-69M-0513
0.750" - 2-56 Nut 3/32 0.094 DIALLYL PHTHALATE Orange M55155/183H02 AA59126/183H02
1127-68M-0514
1127-68M-0514
1127-68M-0514
0.593" - 2-56 Nut 3/32 0.094 DIALLYL PHTHALATE Yellow M55155/184H01 AA59126/184H01
1127-69M-0514
1127-69M-0514
1127-69M-0514
0.750" - 2-56 Nut 3/32 0.094 DIALLYL PHTHALATE Yellow M55155/184H02 AA59126/184H02
1127-69M-09510
1127-69M-09510
1127-69M-09510
0.750" - 2-56 Nut 3/32 0.094 DIALLYL PHTHALATE Black M55155/180I02 AA59126/180I02
1100-07M-08817Z
1100-07M-08817Z
1100-07M-08817Z
0.350" - Press Fit 1/16 0.086 PTFE Violet M55155/087D02 AA59126/087D02
