Commercial
Insulated
Pin Terminals

Filter
1175-801-0411
1175-801-0411
1175-801-0411
0.342" 0.040 - PRESS LOCK 1/32 0.126 (+0.003/-0.001) Brass Electro-Tin - - PTFE Brown NO
1175-841-0411
1175-841-0411
1175-841-0411
0.402" - - PRESS LOCK 1/32 0.126 (+0.003/-0.001) Brass Electro-Tin - - PTFE Brown NO
1121-13-0119
1121-13-0119
1121-13-0119
0.740" 0.050 Turret/Tip Press Fit 1/8 0.158 Brass Silver - - PTFE White YES
1154R-46-0117
1154R-46-0117
1154R-46-0117
0.478" 0.050 Pin/Slotted Press Fit 11/32 0.158 Brass Silver - - PTFE Violet YES
1106R-50-0114
1106R-50-0114
1106R-50-0114
0.350" - - Press Fit 1/16 0.091 Brass Silver - - PTFE Yellow NO
1102-06-0116
1102-06-0116
1102-06-0116
0.531" - - Press Fit 1/16 0.114 Brass Silver - - PTFE Blue YES
1175-403-0117
1175-403-0117
1175-403-0117
0.506" - - PRESS LOCK 3/32 0.142 (+0.003/-0.001) Brass Silver - - PTFE Violet YES
1113-02-0111
1113-02-0111
1113-02-0111
0.303" - - Press Fit 1/32 0.113 Brass Silver - - PTFE Brown NO
1175-404-0117
1175-404-0117
1175-404-0117
0.537" - - PRESS LOCK 1/8 0.142 (+0.003/-0.001) Brass Silver - - PTFE Violet YES
1125-86-0113
1125-86-0113
1125-86-0113
0.760" - - 6-32 Nut 1/8 0.144 Brass Silver Electro-Tin Brass PTFE Orange NO
1121-02-0111
1121-02-0111
1121-02-0111
0.350" 0.040 Turret/Tip Press Fit 1/32 0.113 Brass Silver - - PTFE Brown NO
1125-12-0111
1125-12-0111
1125-12-0111
0.485" - - 2-56 1/8 2-56 THREAD Brass Silver Electro-Tin Brass PTFE Brown NO
1127-32-0111
1127-32-0111
1127-32-0111
0.844" - - 6-32 Nut 1/8 0.144 Brass Silver ZINC Brass DIALLYL PHTHALATE Brown YES
1102-76-0516
1102-76-0516
1102-76-0516
0.655" - - Press Fit Up to 3/16 0.236 Brass Electro Solder - - PTFE Blue NO
1110-69-0110
1110-69-0110
1110-69-0110
0.725" 0.040 Pin/Pin Press Fit 1/8 0.136 Brass Silver - - PTFE Black YES
1160-22-0116
1160-22-0116
1160-22-0116
0.350" - - Press Fit 1/16 0.086 Brass Silver - - PTFE Blue YES
1102-81-0110
1102-81-0110
1102-81-0110
1.143" - - Press Fit 5/32 0.203 Brass Silver - - PTFE Black YES
1102-87-08814
1102-87-08814
1102-87-08814
1.268" - - Press Fit 5/32 0.203 Brass Bright Tin-Lead - - PTFE Yellow NO
1114-10-0113
1114-10-0113
1114-10-0113
0.225" 0.040 - Press Fit 1/32 0.113 Brass Silver - - PTFE Orange NO
1121-32-08812
1121-32-08812
1121-32-08812
0.250" - Turret/Turret Press Fit 1/32 0.070 Brass Bright Tin-Lead - - PTFE Red NO
