Commercial
Insulated
Pin Terminals

Filter
1139-04-0419
1139-04-0419
1139-04-0419
0.405" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE White YES
1139-03-08818
1139-03-08818
1139-03-08818
0.448" 0.030 Pin/Pin Press Fit 1/16 0.070 Brass Bright Tin-Lead - - PTFE Gray NO
1137-03-0513
1137-03-0513
1137-03-0513
0.320" 0.030 Pin/Slotted Press Fit 1/16 0.070 Brass Electro Solder - - PTFE Orange NO
1137-03-04415
1137-03-04415
1137-03-04415
0.320" 0.030 Pin/Slotted Press Fit 1/16 0.070 Brass Bright Tin - - PTFE Green YES
1137-03-0516
1137-03-0516
1137-03-0516
0.320" 0.030 Pin/Slotted Press Fit 1/16 0.070 Brass Electro Solder - - PTFE Blue NO
1135-09-0514
1135-09-0514
1135-09-0514
0.400" 0.030 Pin/Slotted Press Fit 1/16 0.086 Brass Electro Solder - - PTFE Yellow NO
1121-19-04418
1121-19-04418
1121-19-04418
1.115" 0.050 Turret/Tip Press Fit 11/32 0.158 Brass Bright Tin - - PTFE Gray NO
1135-06-0517
1135-06-0517
1135-06-0517
0.425" 0.040 Pin/Slotted Press Fit 1/16 0.113 Brass Electro Solder - - PTFE Violet NO
1112R-18-08813
1112R-18-08813
1112R-18-08813
0.381" - - Press Fit 1/8 0.164 Brass Bright Tin-Lead - - PTFE Orange NO
1127-17-0112
1127-17-0112
1127-17-0112
0.813" - - 6-32 Nut 3/32 0.144 Brass Silver ZINC Brass DIALLYL PHTHALATE Red YES
1131-09-04415
1131-09-04415
1131-09-04415
0.415" 0.040 Pin/Tip Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Green YES
1131-09-0316
1131-09-0316
1131-09-0316
0.415" 0.040 Pin/Tip Press Fit 1/16 0.136 Brass Gold - - PTFE Blue YES
1131-04-0312
1131-04-0312
1131-04-0312
0.562" 0.050 Pin/Tip Press Fit 3/32 0.172 Brass Gold - - PTFE Red NO
1106-16-0519
1106-16-0519
1106-16-0519
0.890" - - Press Fit 5/32 0.205 Brass Electro Solder - - PTFE White NO
1155R-16-0416
1155R-16-0416
1155R-16-0416
0.367" 0.085 - Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Blue YES
1114R-16-08812
1114R-16-08812
1114R-16-08812
0.296" 0.040 - Press Fit 1/16 0.136 Brass Bright Tin-Lead - - PTFE Red NO
1111-16-0117
1111-16-0117
1111-16-0117
0.609" 0.040 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Silver - - PTFE Violet YES
1102-16-0114
1102-16-0114
1102-16-0114
0.428" - - Press Fit 3/32 0.136 Brass Silver - - PTFE Yellow NO
1114-16-08816
1114-16-08816
1114-16-08816
0.296" 0.040 - Press Fit 1/16 0.136 Brass Bright Tin-Lead - - PTFE Blue NO
1151-15-04417
1151-15-04417
1151-15-04417
0.428" - - Press Fit 3/32 0.136 Brass Bright Tin - - PTFE Violet YES
