Commercial
Insulated
Pin Terminals

Filter
09-2094-1-0110
09-2094-1-0110
09-2094-1-0110
0.593" 0.050 ± 0.010 Pin/Hook Press Fit 3/32 0.191 Brass Silver - - PTFE Black YES
1100R-09-08815
1100R-09-08815
1100R-09-08815
0.350" 0.040 - Press Fit 3/32 0.098 Brass Bright Tin-Lead - - PTFE Green NO
1177-05-0312
1177-05-0312
1177-05-0312
0.370" 0.040 - PRESS LOCK 1/32 - 1/16 0.158 Brass Gold - - PTFE Red NO
09-2094-1-0415
09-2094-1-0415
09-2094-1-0415
0.593" 0.050 ± 0.010 Pin/Hook Press Fit 3/32 0.191 Brass Electro-Tin - - PTFE Green YES
09-2090-1-0313
09-2090-1-0313
09-2090-1-0313
1.260" 0.040 (+0.001/-0.005) Pin/Pin Press Fit 1/32 0.076 Brass Gold - - PTFE Orange NO
1156R-07-04419
1156R-07-04419
1156R-07-04419
0.500" 0.040 DOUBLE Turret/Tip Press Fit 3/32 0.136 Brass Bright Tin - - PTFE White YES
1125-44-0312
1125-44-0312
1125-44-0312
0.718" - - 4-40 Screw - CLEARANCE FOR #4 Screw Brass Gold ZINC Brass PTFE Red NO
1156-09-0312
1156-09-0312
1156-09-0312
0.609" 0.040 DOUBLE TURRET/PIN Press Fit 1/16 0.136 Brass Gold - - PTFE Red NO
1154R-07-0117
1154R-07-0117
1154R-07-0117
0.478" - - Press Fit 1/8 0.158 Brass Silver - - PTFE Violet YES
1110-40-0115
1110-40-0115
1110-40-0115
0.675" 0.040 Pin/Pin Press Fit 1/8 0.152 Brass Silver - - PTFE Green YES
1100R-13-0110
1100R-13-0110
1100R-13-0110
0.265" 0.040 - Press Fit 1/16 0.136 Brass Silver - - PTFE Black YES
1102-71-0318
1102-71-0318
1102-71-0318
1.268" - - Press Fit 5/32 0.158 Brass Gold - - PTFE Gray NO
1101-05-0416
1101-05-0416
1101-05-0416
0.428" - - Press Fit 3/32 0.136 Brass Electro-Tin - - PTFE Blue YES
1100R-28-04413
1100R-28-04413
1100R-28-04413
0.350" 0.040 - Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Orange NO
1102-74-04414
1102-74-04414
1102-74-04414
0.375" - - Press Fit 3/32 0.172 Brass Bright Tin - - PTFE Yellow NO
1100-37-0316
1100-37-0316
1100-37-0316
0.460" 0.040 - Press Fit 1/16 0.136 Brass Gold - - PTFE Blue YES
1100-34-0318
1100-34-0318
1100-34-0318
0.410" 0.040 - Press Fit 1/8 0.136 Brass Gold - - PTFE Gray NO
1102-74-0119
1102-74-0119
1102-74-0119
0.375" - - Press Fit 3/32 0.172 Brass Silver - - PTFE White YES
1100-20-04410
1100-20-04410
1100-20-04410
0.365" 0.040 - Press Fit 3/32 0.136 Brass Bright Tin - - PTFE Black YES
1100-18-0515
1100-18-0515
1100-18-0515
0.247" 0.040 - Press Fit 1/32 0.136 Brass Electro Solder - - PTFE Green NO
