Commercial
Insulated
Pin Terminals

Filter
1123-73-08816
1123-73-08816
1123-73-08816
0.602" - - Press Fit Up to 3/16 0.158 Brass Bright Tin-Lead - - PTFE Blue NO
1102-74-08816
1102-74-08816
1102-74-08816
0.375" - - Press Fit 3/32 0.172 Brass Bright Tin-Lead - - PTFE Blue NO
1114-05-08811
1114-05-08811
1114-05-08811
0.317" 0.040 - Press Fit 1/32 0.086 Brass Bright Tin-Lead - - PTFE Brown NO
1106-09-0513
1106-09-0513
1106-09-0513
0.603" - - Press Fit 1/8 0.158 Brass Electro Solder - - PTFE Orange NO
1106-09-0519
1106-09-0519
1106-09-0519
0.603" - - Press Fit 1/8 0.158 Brass Electro Solder - - PTFE White NO
1155-16-0518
1155-16-0518
1155-16-0518
0.367" 0.085 - Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Gray NO
1155-16-0514
1155-16-0514
1155-16-0514
0.367" 0.085 - Press Fit 1/16 0.136 Brass Electro Solder - - PTFE Yellow NO
1127-82-0318
1127-82-0318
1127-82-0318
0.859" - - Swage Mount 3/16 0.147 Brass Gold ZINC Brass DIALLYL PHTHALATE Gray YES
1125-82-04412
1125-82-04412
1125-82-04412
0.694" - - Swage Mount 1/16 0.191 Brass Bright Tin Electro-Tin Brass PTFE Red NO
1125-82-04413
1125-82-04413
1125-82-04413
0.694" - - Swage Mount 1/16 0.191 Brass Bright Tin Electro-Tin Brass PTFE Orange NO
1125-82-04414
1125-82-04414
1125-82-04414
0.694" - - Swage Mount 1/16 0.191 Brass Bright Tin Electro-Tin Brass PTFE Yellow NO
1125-82-04415
1125-82-04415
1125-82-04415
0.694" - - Swage Mount 1/16 0.191 Brass Bright Tin Electro-Tin Brass PTFE Green YES
1125-82-04416
1125-82-04416
1125-82-04416
0.694" - - Swage Mount 1/16 0.191 Brass Bright Tin Electro-Tin Brass PTFE Blue YES
1125-82-04418
1125-82-04418
1125-82-04418
0.694" - - Swage Mount 1/16 0.191 Brass Bright Tin Electro-Tin Brass PTFE Gray NO
1125-82-04419
1125-82-04419
1125-82-04419
0.694" - - Swage Mount 1/16 0.191 Brass Bright Tin Electro-Tin Brass PTFE White YES
1127-82-0119
1127-82-0119
1127-82-0119
0.859" - - Swage Mount 3/16 0.147 Brass Silver ZINC Brass DIALLYL PHTHALATE White YES
1127-82-0519
1127-82-0519
1127-82-0519
0.859" - - Swage Mount 3/16 0.147 Brass Electro Solder ZINC Brass DIALLYL PHTHALATE White NO
1127-82-0517
1127-82-0517
1127-82-0517
0.859" - - Swage Mount 3/16 0.147 Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Violet NO
1125-82-0412
1125-82-0412
1125-82-0412
0.694" - - Swage Mount 1/16 0.191 Brass Electro-Tin Electro-Tin Brass PTFE Red NO
1127-82-08819
1127-82-08819
1127-82-08819
0.859" - - Swage Mount 3/16 0.147 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE White NO
