Commercial
Insulated
Pin Terminals

Filter
1130R-05-0518
1130R-05-0518
1130R-05-0518
1.531" (0.030)/(0.050) Pin/Pin Press Fit Up to 1/4 0.172 Brass Electro Solder - - PTFE Gray NO
1130-05-04418
1130-05-04418
1130-05-04418
1.531" (0.030)/(0.050) Pin/Pin Press Fit Up to 1/4 0.172 Brass Bright Tin - - PTFE Gray NO
1103R-05-0417
1103R-05-0417
1103R-05-0417
0.455" - - Press Fit 5/32 0.136 Brass Electro-Tin - - PTFE Violet YES
1101-05-0312
1101-05-0312
1101-05-0312
0.428" - - Press Fit 3/32 0.136 Brass Gold - - PTFE Red NO
1127-05-0317
1127-05-0317
1127-05-0317
0.938" - - 4-40 Screw - CLEARANCE FOR #4 Screw Brass Gold Electro-Tin Brass DIALLYL PHTHALATE Violet YES
1107-02-04417
1107-02-04417
1107-02-04417
0.560" 0.040 Pin/Pin Press Fit 1/8 0.136 Brass Bright Tin - - PTFE Violet YES
1107-02-04416
1107-02-04416
1107-02-04416
0.560" 0.040 Pin/Pin Press Fit 1/8 0.136 Brass Bright Tin - - PTFE Blue YES
1107-02-04415
1107-02-04415
1107-02-04415
0.560" 0.040 Pin/Pin Press Fit 1/8 0.136 Brass Bright Tin - - PTFE Green YES
1107-02-04413
1107-02-04413
1107-02-04413
0.560" 0.040 Pin/Pin Press Fit 1/8 0.136 Brass Bright Tin - - PTFE Orange NO
1107-02-04411
1107-02-04411
1107-02-04411
0.560" 0.040 Pin/Pin Press Fit 1/8 0.136 Brass Bright Tin - - PTFE Brown NO
1139-02-04410
1139-02-04410
1139-02-04410
0.383" 0.030 (+0.003/-0.000) Pin/Pin Press Fit 1/16 0.070 Brass Bright Tin - - PTFE Black YES
1127-02-0517
1127-02-0517
1127-02-0517
0.423" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Electro Solder Electro Solder Brass DIALLYL PHTHALATE Violet NO
1127-02-0516
1127-02-0516
1127-02-0516
0.423" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Electro Solder Electro Solder Brass DIALLYL PHTHALATE Blue NO
1127-02-0515
1127-02-0515
1127-02-0515
0.423" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Electro Solder Electro Solder Brass DIALLYL PHTHALATE Green NO
1127-02-0514
1127-02-0514
1127-02-0514
0.423" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Electro Solder Electro Solder Brass DIALLYL PHTHALATE Yellow NO
1130-02-0411
1130-02-0411
1130-02-0411
1.870" (0.030)/(0.040) Pin/Pin Press Fit 7/32 0.172 Brass Electro-Tin - - PTFE Brown NO
1127-02-0512
1127-02-0512
1127-02-0512
0.423" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Electro Solder Electro Solder Brass DIALLYL PHTHALATE Red NO
1130-02-0414
1130-02-0414
1130-02-0414
1.870" (0.030)/(0.040) Pin/Pin Press Fit 7/32 0.172 Brass Electro-Tin - - PTFE Yellow NO
1127-02-0511
1127-02-0511
1127-02-0511
0.423" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Electro Solder Electro Solder Brass DIALLYL PHTHALATE Brown NO
1139-02-04411
1139-02-04411
1139-02-04411
0.383" 0.030 (+0.003/-0.000) Pin/Pin Press Fit 1/16 0.070 Brass Bright Tin - - PTFE Brown NO
