Commercial
Insulated
Pin Terminals

Filter
1136-01-04417
1136-01-04417
1136-01-04417
0.312" 0.040 Pin/Pin Press Fit 1/16 0.093 Brass Bright Tin - - PTFE Violet YES
1136-01-04418
1136-01-04418
1136-01-04418
0.312" 0.040 Pin/Pin Press Fit 1/16 0.093 Brass Bright Tin - - PTFE Gray NO
1121R-01-04411
1121R-01-04411
1121R-01-04411
0.350" 0.040 Turret/Tip Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Brown NO
1121R-01-04414
1121R-01-04414
1121R-01-04414
0.350" 0.040 Turret/Tip Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Yellow NO
1160-22-0513
1160-22-0513
1160-22-0513
0.350" - - Press Fit 1/16 0.086 Brass Electro Solder - - PTFE Orange NO
1108-01-08814
1108-01-08814
1108-01-08814
1.687" - Double Turret/Double Turret Press Fit 9/16 0.205 Brass Bright Tin-Lead - - PTFE Yellow NO
1123-01-04419
1123-01-04419
1123-01-04419
0.821" 0.050 TIP/SLOTTED Press Fit Up to 3/16 0.158 Brass Bright Tin - - PTFE White YES
1156-01-0314
1156-01-0314
1156-01-0314
0.460" - DOUBLE Turret/Tip Press Fit 1/32 0.086 Brass Gold - - PTFE Yellow NO
1132-01-08813
1132-01-08813
1132-01-08813
0.645" 0.090 - Solder 7/32 0.0935 Brass Bright Tin-Lead - - PTFE Orange NO
1153-01-04412
1153-01-04412
1153-01-04412
0.475" 0.040 Pin/Pin Press Fit 1/32 0.113 Brass Bright Tin - - PTFE Red NO
1139-01-04411
1139-01-04411
1139-01-04411
0.248" 0.017 Pin/Pin Press Fit 1/64 0.049 Brass Bright Tin - - PTFE Brown NO
1139-01-04412
1139-01-04412
1139-01-04412
0.248" 0.017 Pin/Pin Press Fit 1/64 0.049 Brass Bright Tin - - PTFE Red NO
1139-01-04418
1139-01-04418
1139-01-04418
0.248" 0.017 Pin/Pin Press Fit 1/64 0.049 Brass Bright Tin - - PTFE Gray NO
1139-01-04414
1139-01-04414
1139-01-04414
0.248" 0.017 Pin/Pin Press Fit 1/64 0.049 Brass Bright Tin - - PTFE Yellow NO
1156-01-0316
1156-01-0316
1156-01-0316
0.460" - DOUBLE Turret/Tip Press Fit 1/32 0.086 Brass Gold - - PTFE Blue YES
1121R-01-04415
1121R-01-04415
1121R-01-04415
0.350" 0.040 Turret/Tip Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Green YES
1121R-01-04417
1121R-01-04417
1121R-01-04417
0.350" 0.040 Turret/Tip Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Violet YES
1121R-01-04418
1121R-01-04418
1121R-01-04418
0.350" 0.040 Turret/Tip Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Gray NO
1121R-01-04419
1121R-01-04419
1121R-01-04419
0.350" 0.040 Turret/Tip Press Fit 1/16 0.086 Brass Bright Tin - - PTFE White YES
1103-01-04412
1103-01-04412
1103-01-04412
0.250" - - Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Red NO
