Commercial
Insulated
Pin Terminals

Filter
1102-06-04416
1102-06-04416
1102-06-04416
0.531" - - Press Fit 1/16 0.114 Brass Bright Tin - - PTFE Blue YES
1123-02-0415
1123-02-0415
1123-02-0415
0.821" 0.050 TIP/SLOTTED Press Fit Up to 3/16 0.158 Brass Electro-Tin - - PTFE Green YES
1102-06-04410
1102-06-04410
1102-06-04410
0.531" - - Press Fit 1/16 0.114 Brass Bright Tin - - PTFE Black YES
1123-03-08815
1123-03-08815
1123-03-08815
0.821" 0.050 TIP/SLOTTED Press Fit Up to 3/16 0.158 Brass Bright Tin-Lead - - PTFE Green NO
1156-03-08813
1156-03-08813
1156-03-08813
0.500" 0.040 DOUBLE TURRET/PIN Press Fit 1/16 0.086 Brass Bright Tin-Lead - - PTFE Orange NO
1111-19-0313
1111-19-0313
1111-19-0313
0.836" 0.050 DOUBLE Turret/Tip Press Fit Up to 3/16 0.136 Brass Gold - - PTFE Orange NO
1111-19-04411
1111-19-04411
1111-19-04411
0.836" 0.050 DOUBLE Turret/Tip Press Fit Up to 3/16 0.136 Brass Bright Tin - - PTFE Brown NO
1102-06-04419
1102-06-04419
1102-06-04419
0.531" - - Press Fit 1/16 0.114 Brass Bright Tin - - PTFE White YES
1111-19-04419
1111-19-04419
1111-19-04419
0.836" 0.050 DOUBLE Turret/Tip Press Fit Up to 3/16 0.136 Brass Bright Tin - - PTFE White YES
1114-13-0110
1114-13-0110
1114-13-0110
0.234" 0.040 - Press Fit 1/16 0.136 Brass Silver - - PTFE Black YES
1102-05-04417
1102-05-04417
1102-05-04417
0.359" - - Press Fit 1/16 0.091 Brass Bright Tin - - PTFE Violet YES
1114-13-0114
1114-13-0114
1114-13-0114
0.234" 0.040 - Press Fit 1/16 0.136 Brass Silver - - PTFE Yellow NO
1102-05-04418
1102-05-04418
1102-05-04418
0.359" - - Press Fit 1/16 0.091 Brass Bright Tin - - PTFE Gray NO
1114-13-0412
1114-13-0412
1114-13-0412
0.234" 0.040 - Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Red NO
1102-05-04410
1102-05-04410
1102-05-04410
0.359" - - Press Fit 1/16 0.091 Brass Bright Tin - - PTFE Black YES
1175-443-08816
1175-443-08816
1175-443-08816
0.611" - TURRET/SLOTTED PRESS LOCK 3/32 0.142 (+0.003/-0.001) Brass Bright Tin-Lead - - PTFE Blue NO
1175-444-0415
1175-444-0415
1175-444-0415
0.642" - TURRET/SLOTTED PRESS LOCK 1/8 0.142 (+0.003/-0.001) Brass Electro-Tin - - PTFE Green YES
1102-03-04412
1102-03-04412
1102-03-04412
0.350" - - Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Red NO
1175-444-04417
1175-444-04417
1175-444-04417
0.642" - TURRET/SLOTTED PRESS LOCK 1/8 0.142 (+0.003/-0.001) Brass Bright Tin - - PTFE Violet YES
1102-02-08812
1102-02-08812
1102-02-08812
0.330" - - Press Fit 1/32 0.086 Brass Bright Tin-Lead - - PTFE Red NO
