Insulated
Banana Plugs

Part No	Length	Mates With	AWG	Body Finish	Insulation Material	Color	Spring Finish
01-2524-1-0119	1.000"	Mini JackS/PLUGS	-	Silver	ABS	White	Silver
01-2524-1-0210	1.000"	Mini JackS/PLUGS	-	Nickel	ABS	Black	Nickel
25-2024-1-0118	1.330"	Mini Jack/Standard	-	Silver	ABS	Gray	Silver
25-2024-1-0116	1.330"	Mini Jack/Standard	-	Silver	ABS	Blue	Silver
01-2126-1-0215	1.160"	Standard Jack	ACCEPTS 18 AWG WIRE	Nickel	BUTYRATE	Green	Nickel
01-2071-1-0116	1.563"	Standard Jack	ACCEPTS 16 AWG WIRE	Silver	BUTYRATE	Blue	Silver
01-2524-1-0315	1.000"	Mini JackS/PLUGS	-	Gold	ABS	Green	Gold
01-2524-1-0118	1.000"	Mini JackS/PLUGS	-	Silver	ABS	Gray	Silver
25-2024-1-0311	1.330"	Mini Jack/Standard	-	Gold	ABS	Brown	Gold
01-2016-1-0215	1.813"	Standard Jack	ACCEPTS 14 AWG WIRE	Nickel	BUTYRATE	Green	Nickel
01-2020-1-0116	1.625"	Standard Jack	ACCEPTS 16 AWG WIRE	Silver	BUTYRATE	Blue	Silver
25-2024-1-0312	1.330"	Mini Jack/Standard	-	Gold	ABS	Red	Gold
25-2024-1-0314	1.330"	Mini Jack/Standard	-	Gold	ABS	Yellow	Gold
01-2071-1-0113	1.563"	Standard Jack	ACCEPTS 16 AWG WIRE	Silver	BUTYRATE	Orange	Silver
25-2023-1-04413	1.550"	Standard Jack/Miniature	-	Bright Tin	ABS	Orange	Bright Tin
01-2066-1-0319	1.500"	Standard Jack	ACCEPTS 12 AWG WIRE	Gold	BUTYRATE	White	Gold
01-2126-1-0219	1.160"	Standard Jack	ACCEPTS 18 AWG WIRE	Nickel	BUTYRATE	White	Nickel
01-2066-1-0318	1.500"	Standard Jack	ACCEPTS 12 AWG WIRE	Gold	BUTYRATE	Gray	Gold
01-2016-1-04419	1.813"	Standard Jack	ACCEPTS 14 AWG WIRE	Bright Tin	BUTYRATE	White	Bright Tin
01-2524-1-0111	1.000"	Mini JackS/PLUGS	-	Silver	ABS	Brown	Silver
