Military
Non-Insulated
Terminals

Filter
15-541-2-095
15-541-2-095
15-541-2-095
0.574" TURRET/DOUBLE TURRET Swage Mount 0.105" 1/16 0.116 Brass Hot Solder Dip M55155/14XI04 AA59126/14XI04
15-503-4-05
15-503-4-05
15-503-4-05
0.495" Double Turret/Double Turret Swage Mount 0.145" 1/8 0.076 Brass Electro Solder M55155/15XH03 AA59126/15XH03
15-509-3-088
15-509-3-088
15-509-3-088
0.783" Double Turret/Double Turret Swage Mount 0.125" 3/32 0.204 Brass Bright Tin-Lead M55155/15XJ08 AA59126/15XJ08
15-509-2-088
15-509-2-088
15-509-2-088
0.751" Double Turret/Double Turret Swage Mount 0.093" 1/16 0.204 Brass Bright Tin-Lead M55155/15XJ07 AA59126/15XJ07
15-503-4-095
15-503-4-095
15-503-4-095
0.495" Double Turret/Double Turret Swage Mount 0.145" 1/8 0.076 Brass Hot Solder Dip M55155/15XI03 AA59126/15XI03
15-512-4-05
15-512-4-05
15-512-4-05
0.536" Double Turret/Double Turret Swage Mount 0.165" 1/8 0.129 Brass Electro Solder M55155/15XH06 AA59126/15XH06
15-503-2-095
15-503-2-095
15-503-2-095
0.432" Double Turret/Double Turret Swage Mount 0.082" 1/16 0.076 Brass Hot Solder Dip M55155/15XI01 AA59126/15XI01
15-302-3-095
15-302-3-095
15-302-3-095
0.271" - Swage Mount 0.115" 3/32 0.067 Brass Hot Solder Dip M55155/16XI02 AA59126/16XI02
15-302-3-05
15-302-3-05
15-302-3-05
0.271" - Swage Mount 0.115" 3/32 0.067 Brass Electro Solder M55155/16XH02 AA59126/16XH02
15-302-3-088
15-302-3-088
15-302-3-088
0.271" - Swage Mount 0.115" 3/32 0.067 Brass Bright Tin-Lead M55155/16XJ02 AA59126/16XJ02
15-302-2-095
15-302-2-095
15-302-2-095
0.240" - Swage Mount 0.084" 1/16 0.067 Brass Hot Solder Dip M55155/16XI01 AA59126/16XI01
15-302-4-088
15-302-4-088
15-302-4-088
0.303" - Swage Mount 0.147" 1/8 0.067 Brass Bright Tin-Lead M55155/16XJ03 AA59126/16XJ03
15-349-2-095
15-349-2-095
15-349-2-095
0.437" - Swage Mount 0.109" 1/16 0.116 Brass Hot Solder Dip M55155/17XI01 AA59126/17XI01
15-349-4-05
15-349-4-05
15-349-4-05
0.500" - Swage Mount 0.172" 1/8 0.116 Brass Electro Solder M55155/17XH03 AA59126/17XH03
15-349-3-088
15-349-3-088
15-349-3-088
0.469" - Swage Mount 0.141" 3/32 0.116 Brass Bright Tin-Lead M55155/17XJ02 AA59126/17XJ02
15-349-4-095
15-349-4-095
15-349-4-095
0.500" - Swage Mount 0.172" 1/8 0.116 Brass Hot Solder Dip M55155/17XI03 AA59126/17XI03
15-349-2-088
15-349-2-088
15-349-2-088
0.437" - Swage Mount 0.109" 1/16 0.116 Brass Bright Tin-Lead M55155/17XJ01 AA59126/17XJ01
15R-204-3-095
15R-204-3-095
15R-204-3-095
0.501" - Swage Mount 0.141" 3/32 0.116 Phosphor Bronze Hot Solder Dip M55155/12XC08 AA59126/12XC08
15R-204-2-095
15R-204-2-095
15R-204-2-095
0.469" - Swage Mount 0.109" 1/16 0.116 Phosphor Bronze Hot Solder Dip M55155/12XC07 AA59126/12XC07
15-433-5-05
15-433-5-05
15-433-5-05
0.882" - Swage Mount 0.195" 1/8 0.189 Brass Electro Solder M55155/32XH09 AA59126/32XH09
