Military
Non-Insulated
Terminals

15R-142-1-05
15R-142-1-05
15R-142-1-05
0.147" - Swage Mount 0.053" 1/32 0.043 Phosphor Bronze Electro Solder M55155/11XB09 AA59126/11XB09
15R-142-2-05
15R-142-2-05
15R-142-2-05
0.178" - Swage Mount 0.084" 1/16 0.043 Phosphor Bronze Electro Solder M55155/11XB10 AA59126/11XB10
15R-142-2-088
15R-142-2-088
15R-142-2-088
0.178" - Swage Mount 0.084" 1/16 0.043 Phosphor Bronze Bright Tin-Lead M55155/11XD10 AA59126/11XD10
15R-142-1-088
15R-142-1-088
15R-142-1-088
0.147" - Swage Mount 0.053" 1/32 0.043 Phosphor Bronze Bright Tin-Lead M55155/11XD09 AA59126/11XD09
15R-142-11-088
15R-142-11-088
15R-142-11-088
0.131" - Swage Mount 0.037" 1/64 0.043 Phosphor Bronze Bright Tin-Lead M55155/11XD08 AA59126/11XD08
15R-201-4-088
15R-201-4-088
15R-201-4-088
0.331" - Swage Mount 0.145" 1/8 0.076 Phosphor Bronze Bright Tin-Lead M55155/12XD03 AA59126/12XD03
15R-201-3-05
15R-201-3-05
15R-201-3-05
0.299" - Swage Mount 0.113" 3/32 0.076 Phosphor Bronze Electro Solder M55155/12XB02 AA59126/12XB02
15R-201-4-095
15R-201-4-095
15R-201-4-095
0.331" - Swage Mount 0.145" 1/8 0.076 Phosphor Bronze Hot Solder Dip M55155/12XC03 AA59126/12XC03
15R-201-2-095
15R-201-2-095
15R-201-2-095
0.268" - Swage Mount 0.082" 1/16 0.076 Phosphor Bronze Hot Solder Dip M55155/12XC01 AA59126/12XC01
15R-204-3-095
15R-204-3-095
15R-204-3-095
0.501" - Swage Mount 0.141" 3/32 0.116 Phosphor Bronze Hot Solder Dip M55155/12XC08 AA59126/12XC08
15R-204-4-05
15R-204-4-05
15R-204-4-05
0.532" - Swage Mount 0.172" 1/8 0.116 Phosphor Bronze Electro Solder M55155/12XB09 AA59126/12XB09
15R-204-3-05
15R-204-3-05
15R-204-3-05
0.501" - Swage Mount 0.141" 3/32 0.116 Phosphor Bronze Electro Solder M55155/12XB08 AA59126/12XB08
15R-204-2-05
15R-204-2-05
15R-204-2-05
0.469" - Swage Mount 0.109" 1/16 0.116 Phosphor Bronze Electro Solder M55155/12XB07 AA59126/12XB07
15R-204-2-088
15R-204-2-088
15R-204-2-088
0.469" - Swage Mount 0.109" 1/16 0.116 Phosphor Bronze Bright Tin-Lead M55155/12XD07 AA59126/12XD07
15R-204-2-095
15R-204-2-095
15R-204-2-095
0.469" - Swage Mount 0.109" 1/16 0.116 Phosphor Bronze Hot Solder Dip M55155/12XC07 AA59126/12XC07
15R-204-4-095
15R-204-4-095
15R-204-4-095
0.532" - Swage Mount 0.172" 1/8 0.116 Phosphor Bronze Hot Solder Dip M55155/12XC09 AA59126/12XC09
15R-204-4-088
15R-204-4-088
15R-204-4-088
0.532" - Swage Mount 0.172" 1/8 0.116 Phosphor Bronze Bright Tin-Lead M55155/12XD09 AA59126/12XD09
15R-209-4-05
15R-209-4-05
15R-209-4-05
0.389" - Swage Mount 0.171" 1/8 0.094 Phosphor Bronze Electro Solder M55155/30XB14 AA59126/30XB14
15R-209-3-095
15R-209-3-095
15R-209-3-095
0.358" - Swage Mount 0.140" 3/32 0.094 Phosphor Bronze Hot Solder Dip M55155/30XC10 AA59126/30XC10
15-141-3-095
15-141-3-095
15-141-3-095
0.209" - Swage Mount 0.115" 3/32 0.067 Brass Hot Solder Dip M55155/11XI06 AA59126/11XI06
