Military
Non-Insulated
Terminals

Filter
15R-101-4-095
15R-101-4-095
15R-101-4-095
0.249" - Swage Mount 0.145" 1/8 0.076 Phosphor Bronze Hot Solder Dip M55155/11XC03 AA59126/11XC03
15R-101-2-088
15R-101-2-088
15R-101-2-088
0.186" - Swage Mount 0.082" 1/16 0.076 Phosphor Bronze Bright Tin-Lead M55155/11XD01 AA59126/11XD01
15R-101-4-088
15R-101-4-088
15R-101-4-088
0.249" - Swage Mount 0.145" 1/8 0.076 Phosphor Bronze Bright Tin-Lead M55155/11XD03 AA59126/11XD03
15R-101-2-095
15R-101-2-095
15R-101-2-095
0.186" - Swage Mount 0.082" 1/16 0.076 Phosphor Bronze Hot Solder Dip M55155/11XC01 AA59126/11XC01
15R-101-3-095
15R-101-3-095
15R-101-3-095
0.217" - Swage Mount 0.113" 3/32 0.076 Phosphor Bronze Hot Solder Dip M55155/11XC02 AA59126/11XC02
15R-101-2-05
15R-101-2-05
15R-101-2-05
0.186" - Swage Mount 0.082" 1/16 0.076 Phosphor Bronze Electro Solder M55155/11XB01 AA59126/11XB01
15R-102-1-088
15R-102-1-088
15R-102-1-088
0.265" - Swage Mount 0.078" 1/32 0.082 Phosphor Bronze Bright Tin-Lead M55155/29XD03 AA59126/29XD03
15R-102-1-095
15R-102-1-095
15R-102-1-095
0.265" - Swage Mount 0.078" 1/32 0.082 Phosphor Bronze Hot Solder Dip M55155/29XC03 AA59126/29XC03
15R-102-3-05
15R-102-3-05
15R-102-3-05
0.327" - Swage Mount 0.140" 3/32 0.082 Phosphor Bronze Electro Solder M55155/29XB09 AA59126/29XB09
15R-102-2-095
15R-102-2-095
15R-102-2-095
0.296" - Swage Mount 0.109" 1/16 0.082 Phosphor Bronze Hot Solder Dip M55155/29XC06 AA59126/29XC06
15R-102-4-088
15R-102-4-088
15R-102-4-088
0.357" - Swage Mount 0.170" 1/8 0.082 Phosphor Bronze Bright Tin-Lead M55155/29XD12 AA59126/29XD12
15R-102-4-095
15R-102-4-095
15R-102-4-095
0.357" - Swage Mount 0.170" 1/8 0.082 Phosphor Bronze Hot Solder Dip M55155/29XC12 AA59126/29XC12
15R-103-5-088
15R-103-5-088
15R-103-5-088
0.429" - Swage Mount 0.195" 5/32 0.116 Phosphor Bronze Bright Tin-Lead M55155/29XD14 AA59126/29XD14
15R-103-6-095
15R-103-6-095
15R-103-6-095
0.464" - Swage Mount 0.230" 3/16 0.116 Phosphor Bronze Hot Solder Dip M55155/29XC15 AA59126/29XC15
15R-103-2-05
15R-103-2-05
15R-103-2-05
0.343" - Swage Mount 0.109" 1/16 0.116 Phosphor Bronze Electro Solder M55155/29XB07 AA59126/29XB07
15R-103-6-05
15R-103-6-05
15R-103-6-05
0.464" - Swage Mount 0.230" 3/16 0.116 Phosphor Bronze Electro Solder M55155/29XB15 AA59126/29XB15
15R-103-2-088
15R-103-2-088
15R-103-2-088
0.343" - Swage Mount 0.109" 1/16 0.116 Phosphor Bronze Bright Tin-Lead M55155/29XD07 AA59126/29XD07
15R-103-5-05
15R-103-5-05
15R-103-5-05
0.429" - Swage Mount 0.195" 5/32 0.116 Phosphor Bronze Electro Solder M55155/29XB14 AA59126/29XB14
15R-103-1-088
15R-103-1-088
15R-103-1-088
0.312" - Swage Mount 0.078" 1/32 0.116 Phosphor Bronze Bright Tin-Lead M55155/29XD04 AA59126/29XD04
15-141-3-095
15-141-3-095
15-141-3-095
0.209" - Swage Mount 0.115" 3/32 0.067 Brass Hot Solder Dip M55155/11XI06 AA59126/11XI06
