Military
Insulated
Terminals

Filter
1169-37M-09513Z
1169-37M-09513Z
1169-37M-09513Z
0.750" - 4-40 Nut 1/8 0.120 DIALLYL PHTHALATE Orange M55155/093C04 AA59126/093C04
1133-02M-08816Z
1133-02M-08816Z
1133-02M-08816Z
0.836" DOUBLE TURRET/PIN Press Fit Up to 3/16 0.136 PTFE Blue M55155/046D02 AA59126/046D02
1133-03M-0510Z
1133-03M-0510Z
1133-03M-0510Z
0.500" DOUBLE TURRET/PIN Press Fit 1/16 0.086 PTFE Black M55155/040B03 AA59126/040B03
1133-01M-08810Z
1133-01M-08810Z
1133-01M-08810Z
0.500" DOUBLE TURRET/PIN Press Fit 1/16 0.136 PTFE Black M55155/040D01 AA59126/040D01
1110-75M-08815Z
1110-75M-08815Z
1110-75M-08815Z
0.343" Pin/Pin Press Fit 1/16 0.086 PTFE Green M55155/035D05 AA59126/035D05
1169-36M-09511Z
1169-36M-09511Z
1169-36M-09511Z
0.688" - 4-40 Nut 5/64 0.120 DIALLYL PHTHALATE Brown M55155/091C03 AA59126/091C03
1133-02M-09514Z
1133-02M-09514Z
1133-02M-09514Z
0.836" DOUBLE TURRET/PIN Press Fit Up to 3/16 0.136 PTFE Yellow M55155/044C02 AA59126/044C02
1110-05M-09518Z
1110-05M-09518Z
1110-05M-09518Z
0.515" Pin/Pin Press Fit 1/16 0.086 PTFE Gray M55155/038C04 AA59126/038C04
1133-02M-09517Z
1133-02M-09517Z
1133-02M-09517Z
0.836" DOUBLE TURRET/PIN Press Fit Up to 3/16 0.136 PTFE Violet M55155/047C02 AA59126/047C02
1110-40M-08811Z
1110-40M-08811Z
1110-40M-08811Z
0.675" Pin/Pin Press Fit 1/8 0.152 PTFE Brown M55155/031D03 AA59126/031D03
1133-02M-09519Z
1133-02M-09519Z
1133-02M-09519Z
0.836" DOUBLE TURRET/PIN Press Fit Up to 3/16 0.136 PTFE White M55155/049C02 AA59126/049C02
1110-05M-09510Z
1110-05M-09510Z
1110-05M-09510Z
0.515" Pin/Pin Press Fit 1/16 0.086 PTFE Black M55155/030C04 AA59126/030C04
1133-01M-08813Z
1133-01M-08813Z
1133-01M-08813Z
0.500" DOUBLE TURRET/PIN Press Fit 1/16 0.136 PTFE Orange M55155/043D01 AA59126/043D01
1110-40M-08817Z
1110-40M-08817Z
1110-40M-08817Z
0.675" Pin/Pin Press Fit 1/8 0.152 PTFE Violet M55155/037D03 AA59126/037D03
1133-01M-09519Z
1133-01M-09519Z
1133-01M-09519Z
0.500" DOUBLE TURRET/PIN Press Fit 1/16 0.136 PTFE White M55155/049C01 AA59126/049C01
1110-75M-0515Z
1110-75M-0515Z
1110-75M-0515Z
0.343" Pin/Pin Press Fit 1/16 0.086 PTFE Green M55155/035B05 AA59126/035B05
1110-16M-0517Z
1110-16M-0517Z
1110-16M-0517Z
0.375" Pin/Pin Press Fit 1/16 0.136 PTFE Violet M55155/037B01 AA59126/037B01
1169-36M-09513Z
1169-36M-09513Z
1169-36M-09513Z
0.688" - 4-40 Nut 5/64 0.120 DIALLYL PHTHALATE Orange M55155/093C03 AA59126/093C03
1133-01M-09518Z
1133-01M-09518Z
1133-01M-09518Z
0.500" DOUBLE TURRET/PIN Press Fit 1/16 0.136 PTFE Gray M55155/048C01 AA59126/048C01
1133-01M-09517Z
1133-01M-09517Z
1133-01M-09517Z
0.500" DOUBLE TURRET/PIN Press Fit 1/16 0.136 PTFE Violet M55155/047C01 AA59126/047C01
