Military
Insulated
Terminals

Filter
1169-38M-0518Z
1169-38M-0518Z
1169-38M-0518Z
0.875" - 4-40 Nut Up to 3/16 0.120 DIALLYL PHTHALATE Gray M55155/098B05 AA59126/098B05
1169-38M-0515Z
1169-38M-0515Z
1169-38M-0515Z
0.875" - 4-40 Nut Up to 3/16 0.120 DIALLYL PHTHALATE Green M55155/095B05 AA59126/095B05
1169-38M-0514Z
1169-38M-0514Z
1169-38M-0514Z
0.875" - 4-40 Nut Up to 3/16 0.120 DIALLYL PHTHALATE Yellow M55155/094B05 AA59126/094B05
1169-38M-0512Z
1169-38M-0512Z
1169-38M-0512Z
0.875" - 4-40 Nut Up to 3/16 0.120 DIALLYL PHTHALATE Red M55155/092B05 AA59126/092B05
1169-36M-08816
1169-36M-08816
1169-36M-08816
0.688" - 4-40 Nut 5/64 0.120 DIALLYL PHTHALATE Blue M55155/096J03 AA59126/096J03
1169-38M-08813
1169-38M-08813
1169-38M-08813
0.875" - 4-40 Nut Up to 3/16 0.120 DIALLYL PHTHALATE Orange M55155/093J05 AA59126/093J05
1169-36M-08813
1169-36M-08813
1169-36M-08813
0.688" - 4-40 Nut 5/64 0.120 DIALLYL PHTHALATE Orange M55155/093J03 AA59126/093J03
1169-36M-09519
1169-36M-09519
1169-36M-09519
0.688" - 4-40 Nut 5/64 0.120 DIALLYL PHTHALATE White M55155/099I03 AA59126/099I03
1125-46M-0517Z
1125-46M-0517Z
1125-46M-0517Z
0.718" - 6-32 Screw - CLEARANCE FOR Screw #6 PTFE Violet M55155/107B02 AA59126/107B02
1102-03M-09519Z
1102-03M-09519Z
1102-03M-09519Z
0.350" - Press Fit 1/16 0.086 PTFE White M55155/079C03 AA59126/079C03
1102-03M-09515Z
1102-03M-09515Z
1102-03M-09515Z
0.350" - Press Fit 1/16 0.086 PTFE Green M55155/075C03 AA59126/075C03
1114-23M-08810Z
1114-23M-08810Z
1114-23M-08810Z
0.367" - Press Fit 1/16 0.136 PTFE Black M55155/050D03 AA59126/050D03
1127-06M-09514Z
1127-06M-09514Z
1127-06M-09514Z
0.390" - 2-56 Screw - CLEARANCE FOR Screw #2 DIALLYL PHTHALATE Yellow M55155/204C03 AA59126/204C03
1169-36M-08818
1169-36M-08818
1169-36M-08818
0.688" - 4-40 Nut 5/64 0.120 DIALLYL PHTHALATE Gray M55155/098J03 AA59126/098J03
1102-03M-0513
1102-03M-0513
1102-03M-0513
0.350" - Press Fit 1/16 0.086 PTFE Orange M55155/073H03 AA59126/073H03
1114-23M-09518
1114-23M-09518
1114-23M-09518
0.367" - Press Fit 1/16 0.136 PTFE Gray M55155/058I03 AA59126/058I03
1110-05M-09517
1110-05M-09517
1110-05M-09517
0.515" Pin/Pin Press Fit 1/16 0.086 PTFE Violet M55155/037I04 AA59126/037I04
1117-01M-08813Z
1117-01M-08813Z
1117-01M-08813Z
0.690" TURRET/PIN 12-28 Nut 3/32 0.221 PTFE Orange M55155/023D01 AA59126/023D01
1117-01M-08814Z
1117-01M-08814Z
1117-01M-08814Z
0.690" TURRET/PIN 12-28 Nut 3/32 0.221 PTFE Yellow M55155/024D01 AA59126/024D01
1114-23M-0510
1114-23M-0510
1114-23M-0510
0.367" - Press Fit 1/16 0.136 PTFE Black M55155/050H03 AA59126/050H03

About the Company

CONCORD ELECTRONICS, INC. is a leading manufacturer of high reliability, precision-machined interconnect components, hardware and test accessories. A majority of our parts are proudly Made in the USA and used in a wide variety of industries including: automotive, avionics, energy, industrial, instrumentation, marine, medical, military and telecommunications.  We are a MIL-DTL-39024 recognized manufacturer of both MIL-T-55155 (Group A) and A-A-59126 components
