Commercial
Non-Insulated
Terminals

Filter
10-972-2-035
10-972-2-035
10-972-2-035
0.852" 0.040 - Swage Mount 0.082" 1/16 0.043 Brass Gold YES
10-312-2-035
10-312-2-035
10-312-2-035
0.433" - - Swage Mount 0.105" 1/16 0.082 Brass Gold YES
09-8419-2-035
09-8419-2-035
09-8419-2-035
0.409" 0.062 - Swage Mount 0.084" 1/16 0.067 Brass Gold YES
10-329-6-035
10-329-6-035
10-329-6-035
0.562" - - Swage Mount 0.234" 3/16 0.125 Brass Gold YES
09-8761-2-035
09-8761-2-035
09-8761-2-035
0.829" 0.060 - Swage Mount 0.094" 1/16 0.0635 Brass Gold YES
09-8840-6-035
09-8840-6-035
09-8840-6-035
1.250" 0.1085 - Swage Mount 0.250" 3/16 0.116 Brass Gold YES
10-508-4A-035
10-508-4A-035
10-508-4A-035
0.609" - TURRET/DOUBLE TURRET Swage Mount 0.165" 1/8 0.206 Brass Gold YES
10-973-2-035
10-973-2-035
10-973-2-035
0.852" 0.040 - Swage Mount 0.082" 1/16 0.043 Brass Gold YES
09-0304-1-035
09-0304-1-035
09-0304-1-035
0.154" - - Swage Mount 0.060" 1/32 0.055 Brass Gold YES
09-0159-2-035
09-0159-2-035
09-0159-2-035
0.560" - Double Turret/Double Turret Solder 0.156" 1/32 TO 5/32 0.109 Brass Gold YES
10-505-1-035
10-505-1-035
10-505-1-035
0.385" - TURRET/DOUBLE TURRET Swage Mount 0.062" 1/32 0.094 Brass Gold YES
10-336-1-035
10-336-1-035
10-336-1-035
0.437" - - Swage Mount 0.109" 1/16 0.125 Brass Gold YES
10-119-4-035
10-119-4-035
10-119-4-035
0.393" - - Swage Mount 0.165" 1/8 0.082 Brass Gold YES
09-8706-1-035
09-8706-1-035
09-8706-1-035
0.281" 0.050 - Press Fit/Solder 0.075" 1/16 0.086 Brass Gold YES
10-559-3-035
10-559-3-035
10-559-3-035
0.410" - TURRET/DOUBLE TURRET Swage Mount 0.115" 3/32 0.076 Brass Gold YES
10-101-8-035
10-101-8-035
10-101-8-035
0.374" - - Swage Mount 0.270" 1/4 0.076 Brass Gold YES
09-8764-1-035
09-8764-1-035
09-8764-1-035
0.370" 0.040 - - - - - Brass Gold YES
09-8117-2-035
09-8117-2-035
09-8117-2-035
0.532" 0.041 DOUBLE TURRET/PIN Swage Mount 0.094" 1/16 0.119 Brass Gold YES
09-0230-1-035
09-0230-1-035
09-0230-1-035
0.480" - - Swage Mount 0.055" 1/32 0.094 Brass Gold YES
10-543-2-035
10-543-2-035
10-543-2-035
0.539" - Double Turret/Double Turret Swage Mount 0.094" 1/16 0.094 Brass Gold YES
