Commercial
Non-Insulated
Terminals

Filter
10-885-1-035
10-885-1-035
10-885-1-035
0.395" 0.030 - - - - - Brass Gold YES
10-885-1-03
10-885-1-03
10-885-1-03
0.395" 0.030 - - - - - Brass Gold YES
10-882-5-088
10-882-5-088
10-882-5-088
0.655" - Turret/Turret Swage Mount 0.195" 5/32 0.147 Brass Bright Tin-Lead NO
10-882-5-01
10-882-5-01
10-882-5-01
0.655" - Turret/Turret Swage Mount 0.195" 5/32 0.147 Brass Silver YES
10-902-4-01
10-902-4-01
10-902-4-01
0.344" 0.060 - Swage Mount 0.156" 1/8 0.064 Brass Silver YES
10-902-3-088
10-902-3-088
10-902-3-088
0.313" 0.060 - Swage Mount 0.125" 3/32 0.064 Brass Bright Tin-Lead NO
10-902-3-035
10-902-3-035
10-902-3-035
0.313" 0.060 - Swage Mount 0.125" 3/32 0.064 Brass Gold YES
10-902-3-01
10-902-3-01
10-902-3-01
0.313" 0.060 - Swage Mount 0.125" 3/32 0.064 Brass Silver YES
10-826-5-05
10-826-5-05
10-826-5-05
0.523" - - Swage Mount 0.195" 5/32 0.081 Brass Electro Solder NO
10-826-5-035
10-826-5-035
10-826-5-035
0.523" - - Swage Mount 0.195" 5/32 0.081 Brass Gold YES
10-826-5-01
10-826-5-01
10-826-5-01
0.523" - - Swage Mount 0.195" 5/32 0.081 Brass Silver YES
10-826-3-035
10-826-3-035
10-826-3-035
0.463" - - Swage Mount 0.135" 3/32 0.081 Brass Gold YES
10-846-6-01
10-846-6-01
10-846-6-01
0.558" - - Swage Mount 0.230" 3/16 0.116 Brass Silver YES
10-846-5-088
10-846-5-088
10-846-5-088
0.523" - - Swage Mount 0.195" 5/32 0.116 Brass Bright Tin-Lead NO
10-846-4-044
10-846-4-044
10-846-4-044
0.493" - - Swage Mount 0.165" 1/8 0.116 Brass Bright Tin YES
10-846-3-01
10-846-3-01
10-846-3-01
0.463" - - Swage Mount 0.135" 3/32 0.116 Brass Silver YES
10-840-3-01
10-840-3-01
10-840-3-01
0.518" - - Swage Mount 0.135" 3/32 0.1495 Brass Silver YES
10-840-2-05
10-840-2-05
10-840-2-05
0.488" - - Swage Mount 0.105" 1/16 0.1495 Brass Electro Solder NO
10-840-2-035
10-840-2-035
10-840-2-035
0.488" - - Swage Mount 0.105" 1/16 0.1495 Brass Gold YES
10-840-1-05
10-840-1-05
10-840-1-05
0.458" - - Swage Mount 0.075" 1/32 0.1495 Brass Electro Solder NO
