Insulated
PC Jacks

Filter
1128-54-0316
1128-54-0316
1128-54-0316
0.080 0.250 " 0.586" - Solder 0.062  1/32 - 1/16 Horizontal - - PTFE Blue -
09-9401-1-03515
09-9401-1-03515
09-9401-1-03515
0.080 0.500 " 0.530" Jack/Pin Press Fit 0.177 1/64 - 1/16 Vertical Brass Gold PTFE Green -
1128-54-0315
1128-54-0315
1128-54-0315
0.080 0.250 " 0.586" - Solder 0.062  1/32 - 1/16 Horizontal - - PTFE Green -
09-9012-1-0610
09-9012-1-0610
09-9012-1-0610
0.040 0.190 " 0.390" Jack/Turret Press Fit 0.172 1/32 - 3/16 Vertical Brass Electro-Tin PTFE Black -
09-9175-1-06313
09-9175-1-06313
09-9175-1-06313
0.060 0.214 " 0.413" Jack/Turret Press Fit 0.172 1/32 - 3/16 Vertical Brass Bright Tin-Lead PTFE Orange -
09-9401-1-03517
09-9401-1-03517
09-9401-1-03517
0.080 0.500 " 0.530" Jack/Pin Press Fit 0.177 1/64 - 1/16 Vertical Brass Gold PTFE Violet -
09-9175-1-06315
09-9175-1-06315
09-9175-1-06315
0.060 0.214 " 0.413" Jack/Turret Press Fit 0.172 1/32 - 3/16 Vertical Brass Bright Tin-Lead PTFE Green -
09-9012-1-0611
09-9012-1-0611
09-9012-1-0611
0.040 0.190 " 0.390" Jack/Turret Press Fit 0.172 1/32 - 3/16 Vertical Brass Electro-Tin PTFE Brown -
09-9175-1-06316
09-9175-1-06316
09-9175-1-06316
0.060 0.214 " 0.413" Jack/Turret Press Fit 0.172 1/32 - 3/16 Vertical Brass Bright Tin-Lead PTFE Blue -
09-9158-1-0315
09-9158-1-0315
09-9158-1-0315
0.040 0.297 " 0.750" Jack/Pin Solder 0.047 1/32 - 21/64 Vertical Brass Gold PTFE Green -
09-9011-1-03516
09-9011-1-03516
09-9011-1-03516
0.040 0.190 " 0.390" Jack/Turret Press Fit 0.137 1/32 - 3/16 Vertical Brass Gold PTFE Blue M39024/12-18
09-9010-1-0412
09-9010-1-0412
09-9010-1-0412
0.040 0.195 " 0.343" Jack/Pin Solder 0.027 1/32 - 1/16 Vertical Brass Electro-Tin Polyolefin Red -
09-9012-1-0614
09-9012-1-0614
09-9012-1-0614
0.040 0.190 " 0.390" Jack/Turret Press Fit 0.172 1/32 - 3/16 Vertical Brass Electro-Tin PTFE Yellow -
09-9011-1-03515
09-9011-1-03515
09-9011-1-03515
0.040 0.190 " 0.390" Jack/Turret Press Fit 0.137 1/32 - 3/16 Vertical Brass Gold PTFE Green M39024/12-16
09-9012-1-0617
09-9012-1-0617
09-9012-1-0617
0.040 0.190 " 0.390" Jack/Turret Press Fit 0.172 1/32 - 3/16 Vertical Brass Electro-Tin PTFE Violet -
09-9012-1-06313
09-9012-1-06313
09-9012-1-06313
0.040 0.190 " 0.390" Jack/Turret Press Fit 0.172 1/32 - 3/16 Vertical Brass Bright Tin-Lead PTFE Orange -
09-9012-1-06315
09-9012-1-06315
09-9012-1-06315
0.040 0.190 " 0.390" Jack/Turret Press Fit 0.172 1/32 - 3/16 Vertical Brass Bright Tin-Lead PTFE Green -
09-9012-1-06317
09-9012-1-06317
09-9012-1-06317
0.040 0.190 " 0.390" Jack/Turret Press Fit 0.172 1/32 - 3/16 Vertical Brass Bright Tin-Lead PTFE Violet -
09-9010-1-0416
09-9010-1-0416
09-9010-1-0416
0.040 0.195 " 0.343" Jack/Pin Solder 0.027 1/32 - 1/16 Vertical Brass Electro-Tin Polyolefin Blue -
1138-03-0319
1138-03-0319
1138-03-0319
0.080 0.250 " 0.441" - Swage Mount 0.114 1/32 Vertical - - PTFE White -
