Insulated
PC Jacks

Filter
09-9203-1-03511
09-9203-1-03511
09-9203-1-03511
0.080 0.250 " 0.380" - Solder 0.062  1/32 - 1/16 Horizontal Brass Gold PTFE Brown M39024/4-04
09-9201-1-0314
09-9201-1-0314
09-9201-1-0314
0.080 0.400 " 0.460" - Solder 0.052  1/32 - 1/16 Horizontal - - Nylon Yellow -
09-9203-1-04419
09-9203-1-04419
09-9203-1-04419
0.080 0.250 " 0.380" - Solder 0.062  1/32 - 1/16 Horizontal Brass Bright Tin-Lead PTFE White -
09-9225-1-03519
09-9225-1-03519
09-9225-1-03519
0.080 0.400 " 0.460" - Solder 0.052  1/32 - 1/16 Horizontal - - Nylon White M39024/11-41
09-9265-1-0313
09-9265-1-0313
09-9265-1-0313
0.040 0.190 " 0.605" Jack/Pin Press Fit 0.172 1/32 - 3/16 Vertical Brass Gold PTFE Orange -
09-9084-1-0314
09-9084-1-0314
09-9084-1-0314
0.080 0.340 " 0.453" Jack/Turret Press Fit 0.172 1/32 - 15/64 Vertical Brass Gold PTFE Yellow -
09-9221-1-04413
09-9221-1-04413
09-9221-1-04413
0.080 0.233 " 0.438" Jack/Pin Solder 0.050 1/32 - 1/16 Vertical Brass Bright Tin-Lead Nylon Orange -
09-9084-1-06313
09-9084-1-06313
09-9084-1-06313
0.080 0.340 " 0.453" Jack/Turret Press Fit 0.172 1/32 - 15/64 Vertical Brass Bright Tin-Lead PTFE Orange -
09-9221-1-04414
09-9221-1-04414
09-9221-1-04414
0.080 0.233 " 0.438" Jack/Pin Solder 0.050 1/32 - 1/16 Vertical Brass Bright Tin-Lead Nylon Yellow -
09-9221-1-04416
09-9221-1-04416
09-9221-1-04416
0.080 0.233 " 0.438" Jack/Pin Solder 0.050 1/32 - 1/16 Vertical Brass Bright Tin-Lead Nylon Blue -
09-9252-1-03510
09-9252-1-03510
09-9252-1-03510
0.080 0.400 " 0.460" - Solder 0.052  1/32 Horizontal - - Nylon Black -
09-9071-1-08814
09-9071-1-08814
09-9071-1-08814
0.061 0.190 " 0.656" - - - - - Brass Bright Tin-Lead Polyolefin Yellow -
09-9225-1-03516
09-9225-1-03516
09-9225-1-03516
0.080 0.400 " 0.460" - Solder 0.052  1/32 - 1/16 Horizontal - - Nylon Blue M39024/11-47
09-9084-1-08818
09-9084-1-08818
09-9084-1-08818
0.080 0.340 " 0.453" Jack/Turret Press Fit 0.172 1/32 - 15/64 Vertical Brass Bright Tin-Lead PTFE Gray -
1138-29-03517
1138-29-03517
1138-29-03517
0.080 0.187 " 0.437" Jack/Solder Cup Press Fit 0.172 1/32 - 3/16 Vertical - - PTFE Violet -
09-9011-1-03518
09-9011-1-03518
09-9011-1-03518
0.040 0.190 " 0.390" Jack/Turret Press Fit 0.137 1/32 - 3/16 Vertical Brass Gold PTFE Gray M39024/12-20
09-9208-1-03519
09-9208-1-03519
09-9208-1-03519
0.080 0.400 " 0.460" - Solder 0.052  1/32 - 1/16 Horizontal - - Nylon White M39024/11-41G
09-9012-1-0419
09-9012-1-0419
09-9012-1-0419
0.040 0.190 " 0.390" Jack/Turret Press Fit 0.172 1/32 - 3/16 Vertical Brass Electro-Tin PTFE White -
09-9084-1-06312
09-9084-1-06312
09-9084-1-06312
0.080 0.340 " 0.453" Jack/Turret Press Fit 0.172 1/32 - 15/64 Vertical Brass Bright Tin-Lead PTFE Red -
09-9158-1-0413
09-9158-1-0413
09-9158-1-0413
0.040 0.297 " 0.750" Jack/Pin Solder 0.047 1/32 - 21/64 Vertical Brass Electro-Tin PTFE Orange -
